Power Feed Contact / Water Nozzle / Connected Parts
|
|
- WIRE
GUIDE
|
|
|
OrderNo.
|
Specification
|
|
|
KF101
|
A290-8021-X765 (0.205mm)
A290-8021-X766 (0.255mm)
A290-8021-X767
(0.305mm)
O.P.Q.R.T.W series, mate Upper |
|
|
KF102
KF102T
|
A290-8021-X775 (0.205mm) / A290-8021-Z775 (0.205mm)
A290-8021-X776 (0.255mm)
/ A290-8021-Z776 (0.255mm)
A290-8021-X777 (0.305mm) / A290-8021-Z777
(0.305mm)
O.P.Q.R.T.W mate Lower, Diameter: 0.105 - 0.410 |
|
|
KF103
|
A290-8032-X775 (0.205mm) / A290-8021-Y775 (0.205mm)
A290-8032-X776 (0.255mm)
/ A290-8021-Y776 (0.255mm)
A290-8032-X777 (0.305mm) / A290-8021-Y777
(0.305mm)
W0~W4.V AWF Upper, Diameter: 0.105 - 0.335 |
|
|
KF104
|
A290-8032-X735(0.205mm)
A290-8032-X736(0.255mm)
A290-8032-X737(0.305mm)
T.W seriesAWF Lower
|
|
|
KF104T
|
A290-8032-X765(0.205mm)
A290-8032-X766(0.255mm)
A290-8032-X767(0.305mm)
T.W seriesAWF Lower, Manual for taper 30 Angle.
|
|
|
KF105
|
A290-8018-X443 (0.205mm)
A290-8018-X444 (0.255mm)
A290-8018-X445
(0.305mm)
K, M, N, L, AF Lower, Diameter: 0.105 ~ 0.335 |
|
|
KF106
|
A290-8011-X833 (0.205mm)
A290-8011-X834 (0.255mm)
A290-8011-X865
(0.305mm)
K, M, N, L, AF Lower, Diameter: 0.105 ~ 0.335 |
|
|
KF108
|
A290-8011-X753 (0.205mm)
A290-8011-X754 (0.255mm)
A290-8011-X755
(0.305mm)
K, M, N, L, AF Common, Diameter: 0.105 ~ 0.335
Manual Type, 60A Power supply
|
|
|
KF110
KF110T
|
A290-8101-X733 (0.205mm) / A290-8103-X705 (0.205mm)
A290-8101-X734 (0.255mm)
/ A290-8103-X706 (0.255mm)
A290-8101-X735 (0.305mm) / A290-8103-X707
(0.305mm)
ALPHA -A,B,C,iA,iB series (Manual) Upper // Taper for 45
Angle-Cut |
|
|
KF111
KF111T
|
A290-8101-X743 (0.205mm) / A290-8109-X715 (0.205mm)
A290-8101-X744 (0.255mm)
/ A290-8109-X716 (0.255mm)
A290-8101-X745 (0.305mm) / A290-8109-X717
(0.305mm)
ALPHA-A,B,C,iA,iB Lower // Taper for 45 Angle-Cut |
|
|
KF112
|
A290-8092-X705 (0.205mm) / A290-8092-Z705 (0.205mm)
A290-8092-X706 (0.255mm)
/ A290-8092-Z706 (0.255mm)
A290-8110-X734 (0.255mm) /
A290-8092-X707
(0.305mm) / A290-8092-Z707 (0.305mm)
A290-8092-X704 (0.155mm) /
A290-8092-Z704 (0.155mm)
A290-8092-X702 (0.105mm) / A290-8092-Z702
(0.105mm)
ALPHA-A, B, C, iA, iB AWF Upper // Taper for 45 Angle Cut. |
|
|
KF113
|
A290-8110(8092)-X715 (0.205mm)
A290-8110(8092)-X716
(0.255mm)
A290-8110-Y744 (0.255mm)
A290-8110(8092)-X717 (0.305mm)
A290-8110(8092)-X712
(0.105mm)
A290-8110(8092)-X714 (0.155mm)
ALPHA-A, B, C, iA, iB AWF
Lower |
|
|
KF113T
|
A290-8110-Z715 (0.205mm)
A290-8110-Z716 (0.255mm)
A290-8110-Z717
(0.305mm)
ALPHA-A, B, C, iA, iB AWF Lower
Lower For afor 45
Angle-Cut, Alpha 1b 19mm Length |
|
- POWER FEED CONTACT
|
|
|
OrderNo.
|
Specification
|
Go to TOP |
|
|
KF001
|
A97L-0001-0664-25S1P
Size: 25.4 x 9.5mm
H.L Lower 25mm
|
|
|
KF002
|
A97L-0001-0664-15S1P / A97L-0126-0001 /
Size: 15.9 x 6.4mm
O.P.Q..R.T.W
Upper&Lower 16mm |
|
|
KF003
|
A290-8008-X107
K.N.M Upper & Lower |
|
|
KF004
|
A290-8032-Z882
23.06.332(NOVOTEC)
W1.2.3.4 AF Upper & Lower 16mm |
|
|
KF005
|
A290-8101-X750
ALPHA -1A.1B.0A.0B AWF TYPE Upper & Lower
|
|
|
KF006
|
A290-8110-X750
ALPHA-0C.1C Upper & Lower
size: 23x12x4(Normal
Type) |
|
|
KF006L
|
A290-8110-X750
ALPHA-0C.1C Upper & Lower
size: 30x12x4(Long Type) |
|
|
KF007
|
A290-8048-X759
W-0 Upper |
 |
KF008
|
A290-8119-Z780
size: 26x10x4 / Alpha 1iD series
|
|
KF008L
|
A290-8119-Z780(L30)-
size: 30x10x4 / Alpha iE series
|
| - WATER NOZZLE |
|
|
OrderNo
|
Specification
|
Go to TOP |
|
|
KF124
|
A290-8110-Y774
Jet nozzle Ceramic only, lower D=1.0 mm
∂ -A/B/C/iA/iB AWF
|
 |
KF125-1
|
A290-8102-Y756
Jet nozzle upper ceramic inside D=1.50 mm
∂ -A/B/C/iA/iB AWF
|
 |
KF126
|
A290-8102-X723Nozzle base upper D=58 mm x 19 mmL - 4 screw holes
∂ -A/B series AWF
|
 |
KF127
|
A290-8110-Y723
Nozzle base upper D=58 mm x 19 mmL - 5 screw holes
∂ -C/iA/iC series AWF
|
 |
KF128
|
0.35
(A290-8104-X620)
0.55
(A290-8102-X620)
|
Upper Sub-Guide
∂ - A, B, C, iA, iB, iC, iD, iE Series AWF
Only Ceramic Inserted
|
 |
|
|
KF129
|
A290-8112-Y759
|
DIA 8.0mm
AWF for 30 degree Taper
Upper, Jet nozzle
|
|
 |
F201
|
A290-8021-Y745
|
Water nozzle upper & lowerD=3.0 mm/Special size
|
/P/Q/R/T/W series
Manual OD=25 x 16 mmT
|
|
Water nozzle upper & lowerD=4.0 mm /Special
size
|
|
Water nozzle upper & lowerD=5.5 mm
|
 |
F202
|
A290-8021-Y705
|
Water nozzle lowerD=3.0 mm /Special size
|
O/P/Q/R/T/W series
Manual
|
|
Water nozzle lower D=4.0 mm /Special size
|
|
Water nozzle lower D=5.5 mm
|
 |
F204
|
A290-8037-X879
Water nozzle lower D=5.5 mm
W-1….4 series, AWF OD=28 x 11 mmT
|
 |
F205
|
A290-8032-Y611
Water nozzle upper D=5.5 mm
W-1….4 series, AWF OD=28 x 15 mmT
|
 |
F206
|
A290-8021-V722
Water nozzle cap upper & lower for F201.F202 Stainless
material
|
 |
F206-2
|
Slide shaftfor wire guide / Dies holder
|
 |
F206-Set
|
Nozzle holder assembly
|
 |
F207
|
A290-8048-X771
Water nozzle lowerD=7.0 mm D=24 x 15 mmT
W-0 Manual
|
 |
F208
|
A290-8048-X772
Water nozzle upperD=7.0 mm D=26 x 15 mmT
W-0 Manual
|
 |
F209
|
A290-8111-X772
|
Nozzle upper D=2 mm
|
∂ -A/B/C/iA/iB series
Manual OD40 x 40 mmT
|
|
A290-8111-X774
|
Nozzle upper D=4 mm
|
|
A290-8101-X776
|
Nozzle upper D=6.5 mm
|
|
A290-8101-X777
|
Nozzle upper D=11 mm
|
 |
F210
|
A290-8101-X755
∂ -A/B/C/iA/iB series
Manual OD40 x ID16 x 23 mmT
|
 |
F211
|
A290-8103-X774
|
Nozzle lower D=2.0 mm
|
∂-A/B/C/iA/iB series
Manual OD27 x 16 mmT
|
|
A290-8101-X774
|
Nozzle standard lower D=4.0 mm
|
|
A290-8101-X756
|
Nozzle lower D=6.5 mm
|
|
|
Nozzle lower D=10 mm for taper
|
 |
F212
|
A290-8102-X751
∂-A/B/C/iA/iB series, AWF 23.5 mmT,
Nozzle upper standard D=6.5 mm
|
 |
F213
|
A290-8102-X771
∂-A/B/C/iA/iB series, AWF 25 mmT
Nozzle lower standard D=6.5 mm
|
|
|
F214
|
A290-8102-X775
∂-A/B/C/iA/iB series, AWF 23.5 mmT,
Nozzle upper D= 4.0 mm
|
|
|
F215
|
A290-8102-X774
∂-A/B/C/iA/iB series, AWF 25 mmT
Nozzle lower D= 4.0 mm
|
|
|
F216
|
A290-8102-X752
∂-A/B/C/iA/iB series, AWF 23.5 mmT,
Nozzle D= 12.0 mm
|
|
|
F217
|
A290-8102-X772
∂-A/B/C/iA/iB series, AWF 25 mmT
Nozzle lower D= 12.0 mm
|
 |
F218
|
A290-8109-X776
∂-A/B/C/iA/iB series, Manual OD=40 x 30 mmL
Water nozzle upperD=6.5
mm
|
|
|
F219
|
A290-8119-Z786(4mm), Z787(6.5mm), Z788(12mm), Z791(2mm)
α-0iE α-1iE α-C400iA α-C400iB α-C600iA α-C600iB α-C800iA α-C800iB with AWF Water nozzle lower
|
| - Connected parts of WIRE EDM |
|
|
OrderNo
|
Specification
|
Go to TOP |
 |
F301
|
A290-8005-X722
Isolation plate lower
O/P/Q/R/T/W series Manual
|
 |
F302
|
A290-8021-X709
Isolation plate lower 63 x 75 x 10 mmT
|
 |
F303
|
A290-8032-X334
Isolation plate lower 39 x 73.6 x 12 mmT
W4 series AWF
|
 |
F303W
|
A290-8048-X333
Isolation plate lower 56 x 73 x 10 mmT
W3 series semi-AWF
|
 |
F304
|
A290-8021-X602
Isolation plate upper(Tap max 35 mm) 51 x 33 x 29 mm
|
|
|
F304A
|
Isolation plate upper(Tap max 39 mm) 51 x 31 x 30 mm
W0 old type
|
 |
F305
|
A290-8101-X509
Isolation plate upper 40 x 40 x 34 mm
∂-A/B series
|
 |
F305-1
|
A290-8102-600
Guide base upper 70 x 27 x 48 mm
∂-B series AWF
|
|
|
F305-2
|
A290-8110-X600
Guide base upper 70 x 27 x 35 mm
∂-iB series AWF
|
 |
F306
|
A290-8101-X312
Isolation plate lower D=72 x 15 mmT
∂-A/B/C series
|
 |
F307
|
A290-8101-X761
Guide base lower 75 x 56 x 66 mm
∂-A/B series
|
 |
F307-1
|
A290-8101-X761
Guide base lower 75 x 56 x 66 mm
∂-C series
|
 |
F307-2
|
A290-8110-Y761
Guide base lower 75 x 56 x 66 mm
∂-iA/iB/C series
|
|
|
F307-3
|
A290-8110-Y761
Guide base lower 75 x 56 x 66 mm
∂-iA/iB/iC series
|
|
|
F400
|
A97L-0001-0670
Bearing 1260Z for F401& F402
W series
|
 |
F401
|
A290-8004-X713
Wire sub roller stainless type OD49 x ID6.5 x 6 mm
W series
|
 |
F401A
|
Axle for F401 or F401C
W series
|
 |
F401C
|
A290-8004-X713
Wire sub roller ceramic type OD49 x ID6.5 x 6 mm
W series
|
 |
F401-Set
|
A290-8004-V316
Wire sub roller stainless type full set with axis &
bearing
W series
|
|
|
F401C-Set
|
A290-8004-V316
Wire sub roller ceramic type full set with axis &
bearing
W series
|
|
|
F402
|
A290-8006-X707
Wire sub roller stainless type OD64 x ID6.5 x 6 mm
W series
|
 |
F403
|
A290-8103-X762
Guide base lower stainless type 40 x 40 x 25 mm
∂-A/B series
|
 |
F404
|
A290-8110-Y770
Lower guide block Astainless 59.5 x 49 x 20 mm
∂-iA/iB/iC series AWF/Maual
|
 |
F404-1C
|
A290-8101-X765
Lower ceramic roller OD38 x ID22 x 12 mm
∂-A/B/C/iA/iB series
|
|
|
F404-1
|
A290-8101-X765
Lower roller stainless OD38 x ID22 x 12 mm
∂-A/B/C/iA/iB series
|
 |
F405
|
A290-8101-X394
Feed guide plastic material 13 x 20 x 19 mm
∂-A/B/C series AWF/Maual
|
 |
F406
|
A290-8110-Z382
Pinch roller ceramic (40/28 x 18mmT) D=40/20(included SUS)
x 18 mm
∂-A/B series AWF/Maual
|
 |
F407
|
A290-8110-Z383
Feed roller ceramic OD40/20 x 19 mm
∂-A/B series AWF/Maual
|
 |
F408
|
A290-8102-X393
Feed wire guide polycarbonate 57 x 20 x 20 mm
∂-A/B/C series AWF/Maual
|
 |
F409
|
A290-8101-X371
Brake shoe upper OD140 x 22 mm
∂-A/B/C series AWF/Maual
|
|
|
F409A
|
A290-8111-X371
Brake shoe / Substitute parts =F409 with 4 tap-screw
∂-A/B/C/iA/iB series AWF/Maual
|
 |
F409W
|
A290-8011-V352
|
 |
F409WO
|
A290-8039-V352
Brake shoe upper OD100x 22 mmT
W0 (AWF) series
|
 |
F409i
|
Brake shoe upper OD140 x 22 mmT
∂-/iA/iB series
|
|
|
F410
|
A290-8110-X382
Pinch roller ceramic without bearing (F502) OD40 x ID28 x
30 mmT
∂-C series AWF/Maual
|
|
|
F410B
|
A290-8110-V384#STD
Bearing (F502), ∂-C series AWF/Maual
|
|
|
F411
|
A290-8110-X383
Feed roller ceramic OD40 x ID12 x 30 mmT
∂-C series AWF/Maual
|
 |
F412
|
A290-8110-X762
``
∂-C/iA/iB series AWF/Maual
|
 |
F413
|
A290-8112-X382
Pinch roller D=80 x 22 mmT
∂-0iA/1iA/0iB/1iB AWF/Maual
|
 |
F414
|
A290-8112-X383
Feed roller D=80 x 22 mmT
∂-0iA/1iA/0iB/1iB AWF/Maual
|
 |
F415
|
A290-8037-X330 ( = Fe416)
Pinch roller SUS OD80 x ID11 mm x 18 mmT
O/P/Q/T/W series
|
|
|
F416
|
A290-8037-X331( = Fe415)
Feed roller SUS OD80 x ID28-20 mm x 18 mmT
O/P/Q/T/W series
|
 |
F417
|
A290-8037-X805
Pinch roller OD=60 x ID=28 x 18 mmT
W0 AWF
|
 |
F418
|
A290-8037-X806
Feed roller OD=60 x ID=10 x 18 mmT
W0 AWF
|
 |
F501
|
A97L-0001-0670
|
DRF2280H Lower bearingfor F404-1. F404-1C OD25 x OD22 x ID8
x 7 mmT M422 (608-sus / non-rubber)
|
∂-0iA/1iA/0iB/1iB AWF/Maual
|
 |
F502
|
A97L-0201-0369
|
SS6001LLU Lower bearingfor F406.F410.F417 OD28 x ID12 x 8
mmT (6901RS)
|
∂-A/B/C series
|
|
|
F503
|
A97L-0201-0369
|
SS6203LLU Lower bearing OD40 x ID17 x 12 mmT
|
∂-A/B series
|
|
|
FE420
|
A290-8032-V742
|
Roller assembly - right
|
W0
|
|
|
FE421
|
A290-8032-V746
|
Roller assembly - left
|
W0
|
|
|
FE422C
|
|
Ceramic roller assemblyOD=23 mm
|
W0
|
 |
KFe514 |
A290-8110-X721
UPPER DIE BLOCK
|
|
|
FE704
|
A290-8102-X656
Chuck
|
 |
FE705
|
A290-8102-X657
Cutting electrode 6 x 6 x 10 mmL (ID=2.5 mm)
|
|
|
FE706
|
A290-8102-x752
|
Electrode screw
|
|
 |
FE708
|
A98L-0001-0972
V-packing 4-inch
∂-0iA
|
|
|
FE709
|
A98L-0001-0973
V-packing 6-inch
∂-1iA
|
|
